Rigid VGV Copper Cable 3*1.5mm2 Roll VGV Cable 3*1.5
| Model: | VGV | Insulation: | PVC |
| Sheath: | PVC | Voltage: | 300V/500V |
| Conductor material: | Copper | Minimum Order: | Negotiable |
| High Light: | Rigid VGV copper cable 3x1.5mm2,PVC insulated VGV cable roll,3 core 1.5mm2 copper cable |
||
High-quality rigid VGV copper cable designed for underground applications with excellent electrical properties and durability.
| mm² | Insulation Thickness (mm) | Sheath Thickness (mm) | Average Diameter (mm) | Finished Product Weight (kg/km) | 20°C Conductor Resistance ≤Ω/km |
|---|---|---|---|---|---|
| 2×0.5 | 0.5 | 0.6 | 5.9 | 32.8 | 39 |
| 2×0.75 | 0.5 | 0.6 | 6.3 | 39.2 | 26 |
| 3×0.5 | 0.5 | 0.6 | 6.3 | 42.1 | 39 |
| 3×0.75 | 0.5 | 0.6 | 6.7 | 51.2 | 26 |
| 2×0.75 | 0.6 | 0.8 | 7.2 | 52.3 | 26 |
| 2×1.0 | 0.6 | 0.8 | 7.5 | 59.3 | 19.5 |
| 2×1.5 | 0.7 | 0.8 | 8.6 | 78.7 | 13.3 |
| 2×2.5 | 0.8 | 1 | 10.6 | 119.2 | 7.98 |
| 3×0.75 | 0.6 | 0.8 | 7.6 | 64.8 | 26 |
| 3×1.0 | 0.6 | 0.8 | 8 | 74.3 | 19.5 |
| 3×1.5 | 0.7 | 0.9 | 9.4 | 104.4 | 13.3 |
| 3×2.5 | 0.8 | 1.1 | 11.4 | 157.5 | 7.98 |
| 4×0.75 | 0.6 | 0.8 | 8.3 | 79.4 | 26 |
| 4×1.0 | 0.6 | 0.9 | 9 | 95.5 | 19.5 |
| 4×1.5 | 0.7 | 1 | 10.5 | 134 | 13.3 |
| 4×2.5 | 0.8 | 1.1 | 12.5 | 196 | 7.98 |
| 5×0.75 | 0.6 | 0.9 | 9.3 | 191.6 | 26 |
| 5×1.0 | 0.6 | 0.9 | 9.8 | 114.1 | 19.5 |
| 5×1.5 | 0.7 | 1.1 | 11.6 | 165.8 | 13.3 |
| 5×2.5 | 0.8 | 1.2 | 13.9 | 242.3 | 7.98 |
- Produced according to standards BS6500, IEC60227:1993, VDE 0281
- BS6360 Class 5, Solid or Stranded Bare Copper Conductor
- BS7655 TI 1 PVC Insulation
- PVC Sheathed, various colors available
This cable is suitable for fixed wiring of power devices, power lighting of home electric equipment and instruments, inner wiring of electric equipment, electronic equipment, and automation devices.
Ideal for use in conduit and for fixed, protected installation of wiring for burglar alarm systems, public address systems, intercoms, telephone stations, speakers, instrumentation, control systems, and other low voltage circuits that require power limitation and anti-interference capabilities.
-
