MinfengXLPE Insulated Armored Cable 1.5mm² to 1000mm² Copper Conductor LV MV Power Cable
| Product name: | Armoured Cable | Standard: | IEC 60502, IEC 60228, IEC 60332, GB/T 12706.1, BS 5467 |
| Cable type: | Armoured | Sheath material: | PVC |
| Cablesize: | Varies From 1.5mm² To 1000mm² | Conductor material: | Copper |
| Flame retardant: | Yes/No | Insulation material: | XLPE |
| High Light: | XLPE insulated armored power cable,copper conductor armored cable,LV MV armoured cable |
||
Minfeng XLPE insulated armoured cable is available in conductor sizes from 1.5mm² to 1000mm², with 1 to 4 core configurations and copper or aluminium conductors. The range covers low voltage (LV) and medium voltage (MV) power cable designs for power transmission and distribution networks, with SWA, STA, AWA and unarmoured options to suit different installation conditions.
| Component | Specification |
|---|---|
| Conductor | Plain stranded copper or aluminium |
| Insulation | Cross-linked polyethylene (XLPE) for high temperature resistance, excellent dielectric strength and enhanced electrical properties |
| Bedding | Protective barrier layer between the insulation and the armour |
| Armour | SWA, STA, AWA or non-armoured options available |
| Sheath | Holds cable components together with additional protection; black sheaths can be carbon-loaded for UV stability |
| Voltage | 600/1000V, 6.35/11kV and 19/33kV ratings |
Underground low voltage cables provide optimal safety and environmental protection for subscribers. Minfengcable offers a comprehensive range of LV underground power cables for creating, renewing and extending power transmission and distribution networks worldwide. Our distinct advantage lies in a relentless commitment to quality, supported by superior technical expertise and extensive manufacturing capabilities.
- Unarmoured cables are designated for general use, including underground burial where mechanical damage is unlikely.
- Armoured cables are most suitable for underground burial applications where there is a risk of mechanical damage.
- International: IEC 60502, IEC 60228, IEC 60332
- National: GB/T 12706.1, BS 5467
- Other standards such as BS, DIN and ICEA available upon request
| Parameter | Details |
|---|---|
| Product Name | Copper core or aluminium core XLPE insulated PVC sheathed power cable; steel tape armoured PVC sheathed power cable; steel wire armoured PVC sheathed power cable |
| Rated Voltage | 0.6/1kV, 1.8/3kV, 3.6/6kV, 6/10kV, 8.7/15kV, 12/20kV, 21/35kV, 26/35kV |
| Standard | GB/T 12706-2008, GB/T 12703-200, IEC 60502-1-1997 |
| Model | YJV, YJLV, YJV22, YJLV22, YJV32, YJLV32, YJV42, YJLV42 |
| Armoured | Steel tape armoured, steel wire armoured; double galvanized steel tape or galvanized steel wire for three core power cable; double aluminium tape or aluminium wire for single power cable |
| Number of Cores | Single core, 2 cores, 3 cores, 4 cores, 5 cores, 3+1 cores, 3+2 cores, 4+1 cores, etc. |
| Common Size | 1mm², 1.5mm², 2.5mm², 4mm², 6mm², 10mm², 16mm², 25mm², 35mm², 50mm², 70mm², 95mm², 120mm², 150mm², 185mm², 240mm², 300mm², 400mm², 500mm², 630mm², 800mm², 1000mm², etc. |
| Types | Ordinary type, flame-retardant type, fire-resistant type, low-smoke halogen-free type |
| Application | Power distribution engineering, power transmission engineering, electromechanical and hydropower installation engineering, power transmission, power supply installation systems, control systems, etc. |
-
